Thickness, GSM, and Specifications of PP Sheets
Depending on the application, PP sheets are available in different thicknesses and corresponding GSM (gram per square meter) values. Below is a detailed breakdown of common specifications:
| Thickness (mm) | Min. GSM | Standard GSM | Max. GSM | Max. Width | Max. Length |
|---|---|---|---|---|---|
| 2mm | 280 | 300 | 500 | 2m | 150m |
| 3mm | 450 | 500 | 800 | 3m | 150m |
| 4mm | 600 | 700 | 1000 | 2.5m | 10m |
| 5mm | 850 | 900 | 1200 | 2.5m | 10m |
| 6mm | 1100 | 1200 | 1800 | 2.5m | 10m |
| 7mm | 1200 | 1400 | 2000 | 2.5m | 10m |
| 8mm | 1800 | 2000 | 2200 | 2.5m | 10m |
| 9mm | 1900 | 2100 | 2500 | 2.5m | 10m |
| 10mm | 2000 | 2200 | 3000 | 2.5m | 10m |
| 11mm | 2400 | 2600 | 3100 | 2.5m | 10m |
| 12mm | 2400 | 2600 | 3300 | 2.5m | 10m |
Key Features
-
- Chemical Resistance: Widely used in chemical industries for its outstanding resistance to acids and alkalis.
-
- High Mechanical Strength: Even thinner sheets maintain sufficient strength for various mechanical applications.
-
- Heat Resistance: Capable of withstanding high temperatures during prolonged use.
-
- Easy to Process: PP sheets can be cut, welded, or thermoformed to meet various production needs.
-
- Eco-Friendly: Polypropylene is non-toxic and fully recyclable, making it an environmentally responsible choice.
Applications
PP plastic sheets are widely used in industries such as chemical processing, food, electronics, electrical, and manufacturing. Common uses include:
-
- Chemical tanks and containers
-
- Water treatment systems
-
- Conveyor systems
-
- Protective casings for electronic components
